FAB

Friability

Product Category: Tablet Testing

Industry: Pharmaceutical, Personal Care and Natural Products

Supplier: Logan Instruments

Description

The FAB-2S Friability Tester is the latest device to test themechanical strength of tablets‚ meeting all current USP and BPrequirements. The FAB-2S is designed for use with both friability andabrasion drums‚ and either one or two drums can be used at a time. Thespeed of the rotation is fixed at 25 RPM as per the USP requirement.

In use‚ the operator loads the tablets into the drum‚ and places it onthe drive shaft. The test time or number of rotations can be selectedand easily entered via the keypad. The inputted data and rotation ortime countdown are clearly indicated on the LED display.

The drums are constructed from Plexiglas and separated into two parts‚the drum body and drum cover. The cover is easily removed to facilitatefilling or discharging of the samples and cleaning the inside of thedrum. The FAB-2S is made of high quality metal with an acid resistantfinish and meets all GLP requirements.

Feature:

  • Meets all current USP‚ BP guidelines
  • LED Display for TIME or COUNTER
  • Microprocessor Control
  • Easy - To - Use Keypad
  • Modular Design for One or Two Drums
  • Rugged Construction For Years Of Dependable Performance
  • Can be used with Abrasion drums
  • Special drums / custom design drums available

Specifications

Drum Position..................................•_•_ •_•_•_...•_2
Drum Speed............•_•_•_•_•_•_•_•_•_•_•_•_•_.......Fixed at 25 rpm
Speed Accuracy Per Minute.•_•_•_•_•_•_•_•_.......... ± 1rpm
Maximum Testing Time .....•_•_•_•_•_•_•_•_•_.........9:59" 59"
Maximum Count of Revolutions...•_•_•_•_•_•_•_•_....99999
Size..............•_•_•_•_•_•_•_•_•_•_•_•_.....................12" X 16" X 14"
Weight .............................•_•_•_•_•_•_•_•_.............. 20 lbs.
Voltage..................•_•_•_•_•_•_•_•_•_•_•_•_•_•_......110_120 VAC/60Hz
-or-  220_240 VAC/60Hz

Accessories

Part No.
Description
210-1000
USP Drum Assembling‚ Left
210-1001
USP Drum Assembling‚ Right
210-1002
Abrasion Drum Assembling‚ Left
210-1003
Abrasion Drum Assembling‚ right
210-1004
Drum nut
10 degree angle spacer
